Material Details & Specifications
| 6061 GENERAL DETAILS | |
|---|---|
| Sourced from | USA/Global |
| CNC MACHINING SPECIFICATIONS | |
| Cutting process | CNC |
| Cut tolerance +/- | 0.005" |
| Min part size | .5″ x .5″x .5" |
| Max part size | 7″ x 7″x 12" |
| ANODIZING SPECIFICATIONS | |
| Min anodizing part size | 1″ x 1″ x 1" |
| Max anodizing part size | 7" x 7" x 12" |
| 6061 PROPERTIES | |
| Material Composition | Aluminum (Al): 95.9 – 98.6 Magnesium (Mg): 0.8 – 1.2 Silicon (Si): 0.4 – 0.8 Iron (Fe): 0 – 0.7 Copper (Cu): 0.15 – 0.4 Chromium (Cr): 0.040 – 0.35 Zinc (Zn): 0 – 0.25 Manganese (Mn): 0 – 0.15 Titanium (Ti): 0 – 0.15 Residuals: 0 – 0.15 |
| Density | 169.344 lb/ft^3 |
| Heat treatments process | T6511B |
| ASTM | B221-21 |
| Tensile Strength (Ultimate) | 51.9 ksi |
| Tensile Strength (Yield) | 47.4 ksi |
| Shear Strength | 30 ksi |
| Shear Modulus | 3800 ksi |
| Fatigue Strength | 14 ksi |
| Hardness | RE 91 |
| Elongation at Break | 13.1% |
| Elastic Modulus | 10000 ksi |
| Poisson’s Ratio | .33 |
| Thermal Conductivity | 170 BTU/h-ft °F |
| Melting Point | 1080 °F |
| Magnetic | No |
| Does it Rust | No |
